使用 Python 中的 WebRTC 构建实时流媒体应用程序

本文分享如何使用 Python 建立 WebRTC 连接，以便将摄像头帧从一台机器流式传输到另一台机器。WebRTC（Web实时通信）可实现点对点通信，是实时视频流等任务的理想选择。

前提条件

• 在发送方和接收方计算机上安装 Python。
• Python 编程基础知识。
• 可使用终端或命令行界面。

设置环境：

首先安装必要的库。运行以下命令安装所需的依赖库：

pip install aiortc opencv-python

发送脚本（远程机器）

发送脚本从摄像头捕捉视频帧并将其发送到接收方。以下是 sender.py 脚本：

import asyncio
import cv2
from aiortc import RTCPeerConnection, RTCSessionDescription, VideoStreamTrack
from aiortc.contrib.signaling import TcpSocketSignaling
from av import VideoFrame
import fractions
from datetime import datetime

class CustomVideoStreamTrack(VideoStreamTrack):
    def __init__(self, camera_id):
        super().__init__()
        self.cap = cv2.VideoCapture(camera_id)
        self.frame_count = 0

    async def recv(self):
        self.frame_count += 1
        print(f"Sending frame {self.frame_count}")
        ret, frame = self.cap.read()
        if not ret:
            print("Failed to read frame from camera")
            return None
        frame = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
        video_frame = VideoFrame.from_ndarray(frame, format="rgb24")
        video_frame.pts = self.frame_count
        video_frame.time_base = fractions.Fraction(1, 30)  # Use fractions for time_base
        # Add timestamp to the frame
        timestamp = datetime.now().strftime("%Y-%m-%d %H:%M:%S.%f")[:-3]  # Current time with milliseconds
        cv2.putText(frame, timestamp, (10, 30), cv2.FONT_HERSHEY_SIMPLEX, 1, (0, 255, 0), 2, cv2.LINE_AA)

        frame = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
        video_frame = VideoFrame.from_ndarray(frame, format="rgb24")
        video_frame.pts = self.frame_count
        video_frame.time_base = fractions.Fraction(1, 30)  # Use fractions for time_base
        return video_frame

async def setup_webrtc_and_run(ip_address, port, camera_id):
    signaling = TcpSocketSignaling(ip_address, port)
    pc = RTCPeerConnection()
    video_sender = CustomVideoStreamTrack(camera_id)
    pc.addTrack(video_sender)

    try:
        await signaling.connect()

        @pc.on("datachannel")
        def on_datachannel(channel):
            print(f"Data channel established: {channel.label}")

        @pc.on("connectionstatechange")
        async def on_connectionstatechange():
            print(f"Connection state is {pc.connectionState}")
            if pc.connectionState == "connected":
                print("WebRTC connection established successfully")

        offer = await pc.createOffer()
        await pc.setLocalDescription(offer)
        await signaling.send(pc.localDescription)

        while True:
            obj = await signaling.receive()
            if isinstance(obj, RTCSessionDescription):
                await pc.setRemoteDescription(obj)
                print("Remote description set")
            elif obj is None:
                print("Signaling ended")
                break
        print("Closing connection")
    finally:
        await pc.close()

async def main():
    ip_address = "xxx.xxx.xx.xx" # Ip Address of Remote Server/Machine
    port = 9999
    camera_id = 2  # Change this to the appropriate camera ID
    await setup_webrtc_and_run(ip_address, port, camera_id)

if __name__ == "__main__":
    asyncio.run(main())

接收方脚本（本地机器）

接收方脚本从发送方接收视频帧并将其显示出来。以下是 receiver.py 脚本：

import asyncio
import cv2
import numpy as np
from aiortc import RTCPeerConnection, RTCSessionDescription, MediaStreamTrack
from aiortc.contrib.signaling import TcpSocketSignaling
from av import VideoFrame
from datetime import datetime, timedelta

class VideoReceiver:
    def __init__(self):
        self.track = None

    async def handle_track(self, track):
        print("Inside handle track")
        self.track = track
        frame_count = 0
        while True:
            try:
                print("Waiting for frame...")
                frame = await asyncio.wait_for(track.recv(), timeout=5.0)
                frame_count += 1
                print(f"Received frame {frame_count}")

                if isinstance(frame, VideoFrame):
                    print(f"Frame type: VideoFrame, pts: {frame.pts}, time_base: {frame.time_base}")
                    frame = frame.to_ndarray(format="bgr24")
                elif isinstance(frame, np.ndarray):
                    print(f"Frame type: numpy array")
                else:
                    print(f"Unexpected frame type: {type(frame)}")
                    continue

                 # Add timestamp to the frame
                current_time = datetime.now()
                new_time = current_time - timedelta( seconds=55)
                timestamp = new_time.strftime("%Y-%m-%d %H:%M:%S.%f")[:-3]
                cv2.putText(frame, timestamp, (10, frame.shape[0] - 30), cv2.FONT_HERSHEY_SIMPLEX, 1, (0, 255, 0), 2, cv2.LINE_AA)
                cv2.imwrite(f"imgs/received_frame_{frame_count}.jpg", frame)
                print(f"Saved frame {frame_count} to file")
                cv2.imshow("Frame", frame)

                # Exit on 'q' key press
                if cv2.waitKey(1) & 0xFF == ord('q'):
                    break
            except asyncio.TimeoutError:
                print("Timeout waiting for frame, continuing...")
            except Exception as e:
                print(f"Error in handle_track: {str(e)}")
                if "Connection" in str(e):
                    break
        print("Exiting handle_track")
async def run(pc, signaling):
    await signaling.connect()

    @pc.on("track")
    def on_track(track):
        if isinstance(track, MediaStreamTrack):
            print(f"Receiving {track.kind} track")
            asyncio.ensure_future(video_receiver.handle_track(track))

    @pc.on("datachannel")
    def on_datachannel(channel):
        print(f"Data channel established: {channel.label}")

    @pc.on("connectionstatechange")
    async def on_connectionstatechange():
        print(f"Connection state is {pc.connectionState}")
        if pc.connectionState == "connected":
            print("WebRTC connection established successfully")

    print("Waiting for offer from sender...")
    offer = await signaling.receive()
    print("Offer received")
    await pc.setRemoteDescription(offer)
    print("Remote description set")

    answer = await pc.createAnswer()
    print("Answer created")
    await pc.setLocalDescription(answer)
    print("Local description set")

    await signaling.send(pc.localDescription)
    print("Answer sent to sender")

    print("Waiting for connection to be established...")
    while pc.connectionState != "connected":
        await asyncio.sleep(0.1)

    print("Connection established, waiting for frames...")
    await asyncio.sleep(100)  # Wait for 35 seconds to receive frames

    print("Closing connection")

async def main():
    signaling = TcpSocketSignaling("192.168.30.40", 9999)
    pc = RTCPeerConnection()

    global video_receiver
    video_receiver = VideoReceiver()

    try:
        await run(pc, signaling)
    except Exception as e:
        print(f"Error in main: {str(e)}")
    finally:
        print("Closing peer connection")
        await pc.close()

if __name__ == "__main__":
    asyncio.run(main())

运行脚本：

在带有摄像头的远程机器上运行发送方脚本：

python sender.py

在您想要显示视频帧的机器上运行接收方脚本：

python receiver.py

结束语

至此您已成功建立了 WebRTC 连接，可以使用 Python 将摄像头帧从一台机器流式传输到另一台机器。本示例为更高级的应用（如远程监控和视频会议）奠定了基础。您可以根据自己的需要对本项目进行定制和扩展。

要深入了解代码，请查看 GitHub 上的项目库：https://github.com/eknathmali/Real-Time-Video-Streaming-with-WebRTC-and-Python

作者：Eknath Bhagwan Mali
